Power Foldaway Mirror Switch - RHD: Removal

Disconnect and isolate the battery negative cable.
Remove the lower instrument panel bezel from under steering column.
Remove the instrument panel end cover retaining screws and pull rearward to release retaining clips.
Disconnect power mirror switch electrical connector (Fig 1 ).

Fig 1: Identifying RHD Power Mirror Switch Location
Courtesy of DAIMLERCHRYSLER CORP.
Remove the mirror switch retaining screws and remove the switch from the end cover.
